Monarch 7.62 Inconel

Description

Specs:

• Material: 718 Inconel
• Method of Manufacturing: DMLS
• Weight: 20.4 oz
• Length: 6.47″ (without a mount)
• Diameter: 1.75″
• Bore: .30 cal
• Finish: C Series Cerakote (Black, FDE, ODG, or RAW media blasted finish)
• No mount is included, but we recommend closed tined flash hiders or brakes to be ran with our design. 3 prong flash hiders are not recommended as it diminishes performance based on our findings with in-house testing
• Barrel length restrictions: 7.5” 5.56 & similar cartridges, 5.5” supersonic .300blk, 10.5” .308 and similar cartridges, 16” .300 win Mag and larger magnum .30cals
• Full Auto Rating: Be Conservative and allow for cool down time every 270 rounds. Belt Fed rating will be tested in the future

Design Highlights:

• “PFM” Baffle Technology (Preferential Flow Management) is incredibly efficient in both flow regimes while maintaining minimal back pressure
• Venting array helps direct sound away from the shooter and bystanders behind the muzzle
• Incredible flash suppression for a high flow rate design
• 718 Inconel allows for heavy abuse and firing schedule
• DMLS manufacturing method allows for design elements not seen in other technologies
• Maintains suppression efficiency even on small calibers like 5.56
• Integral DMLS printed flash hider end cap
• Knurling design helps with removal/tightening of suppressor by hand
• Wrench flats (1.5″) to help with install or removal of mounting system
• 1.375×24 HUB threads allows user to run mounting system of their choice
• Intended cartridges: .300 BLK, 7.62x39mm, .308 win, 5.56. (.30 cal and smaller)

MONARCH 7.62 USERS MANUAL (Included in the box as well)

Mounts: All 1.375×24 RH TPI Mounts will work. Distance from shoulder to blast baffle is 1.59”. Please check mount and can with an alignment rod while mounted to an empty/unloaded rifle.

Cleaning: We recommend the Monarch 7.62 be cleaned in an ultrasonic cleaner with a Cerakote safe solution every 5000-10,000 rounds or when you feel performance has been reduced. We can do this for a flat fee. See website.

Warranty: If it is our fault, we will take care of you at no expense. If it is your fault, it will be on a case by case basis and up to our discretion. If it is due to gross negligence you will be covering the cost of the repair.

Anything we didn’t cover? Email us.
